Certifications & Approvals
Temperature Range
- -40° to 85° C (-4° to 185° F)
Pressure
- Measurement Functional from -4 to 44 psi (-0.25 to 3.00 bar)
Measurement Range
- C10 Sensor: 0.35 to 10.00 m (14 in to 32 ft)
- C06 Sensor: 0.25 to 6.00 m (10 IN to 20 ft)
Beam Angle (at –3 dB, Full Angle)
- C06 Sensor: 7°
- C10 Sensor: 5°
Accuracy
- ± 2 mm (0.08 in) or 0.20 % of Full Span (The Larger of the Two)
Repeatability
- ± 0.2 % of Measurement Range
Housing Material
- Plastic Parts: PVDF
- Metal Parts: Aluminum Alloy
Cable Entry
- 127 mm (0.5 in) Threaded Bore for Cable Gland, Directly on Housing
- M20 x 1.5 Threaded Bore for Cable Gland, Directly on Housing
Dimensions (L x W x H)
- 136 x 100 x 266 mm (5.3" x 3.9" x 10.5")
