Profibus PA/DP Segment Coupler

Brand: VEGA
Vega Profibus PA/DP Segment Coupler
Images are representations only.

Profibus PA/DP Segment Coupler

Brand: VEGA
Request Information Favorite
For use in conjunction with Profibus DP/PA bus systems.

The segment coupler is suitable for coupling and power supply of Profibus PA networks.

The Ex version ensures Ex intrinsic safety in conjunction with Ex circuits.
Features
  • Simple setup because no own GSD, DTM or EDD file or Profibus address must be used
  • Reliable connection to Ex circuits by standardized FISCO procedure
  • Economical, compact version with up to 10 Ex or 32 non-Ex field devices

Specifications

Brand

Ambient Temperature Range

  • -20° to 60° C (-4° to 140° F)

Approvals & Certifications

  • ATEX

Communication

  • Baud Rate: 93,750 bit/sec - PROFIBUS DP
  • PROFIBUS DP
  • PROFIBUS PA

Environmental Protection

  • IP20

Input Signal

  • FOUNDATION Fieldbus

Mounting

  • Carrier Rail 35 x 7.5 According to EN 50022

Output

  • FOUNDATION Fieldbus

Supply Voltage

  • 13 V with 100 mA - PROFIBUS PA
  • 24 V with 400 mA - PROFIBUS PA
