Specifications
Scale Range
- 1 … 2.4 inH₂O Vertical scale
- 0 to 0.8 inH₂O horizontal Scale
Operating Temperature
- Medium: -40° to +140° F
- Ambient: -40° to +140° F
Ingress Protection
- NEMA 3 (IP54 per EN 60 529 / lEC 529)
Process Connection
- Hose Barb Nozzles (ABS) for 1/8" and 1/4" Hose I.D.
Liquid Filling
- Red, Specific Gravity 0.786 kg/dm³ (At 60° F), 30 ml
Mounting Position
- Horizontal Wall Mount position
Standard Accessories
- 2 Mounting Screws
- Filling Liquid
- Red and Green Pressure limit label
- Monitoring differential pressure of air and other non-combustible, non aggressive gases.
- Monitoring of ventilators, fans and filters in climatic chambers and clean rooms.
- Filter monitoring in paint booths
